3. ATTACHED FITTINGS
Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully.
QUANTITY
SHAPE
NAME
2. Plastic expanded tube
4.D rain pipe
3. Wrapping tape
5. Wall conduit cover
10. Owner's manual
11. Installation manual
12. seel gasket
7. Frame
8. Mounting screw(ST2.9
10-C-H)
9. Alkaline dry batteries (AM4)
8
8
1
1
1
1
1
2
2
1
1
FUNCTION
Secure the installation board
This manual
Hold the remote controller
6. Remote controller
(including operation manual)
Insulation Holder for remote controller
Fig.3-1
Never throw or beat the controller.
Before installation, operate the remote controller to determine its location in a
reception range.
Keep the remote controller at least 1m apart from the nearest TV set or stereo
equipment. (it is necessary to prevent image disturbances or noise interferences.)
Do not install the remote controller in a place exposed to direct sunlight or close to a
heating source, such as a stove.
Note that the positive and negative poles are right positions when loading batteries.
This manual is subject to changes due to technological improvement without further
notices.
Cautions on remote controller installation:
Remote
controller
Remote controller
holder
Mounting screw B
ST2.9x10-C-H
CANCEL
LOCK
SET TEMPERATURE(°C)
AUTO
COOL
DRY
HEAT
FA N
HIGH
MED
LOW
TEMP
MODE
SWING TIMER
RESET
ON/OFF
FAN
SPEED
VENT
ECONOMIC
RUNNING
1. Screw ST3.9x25 for installation board
4
For connect water pipe
To Next Page
