User Manual of A90 Series Inverter
23
(d) Appearance of A90-4T060KEY3 external keyboard
Fig. 2-1 Outline Dimensions of A90 Series Inverter and Keyboard
Table 2-2 Outline and Installation Dimensions of A90 Series Inverter
Specifications
W
W1/W2
H
H1
H2
D
D1
d
A90-2T2R8B
75
65
142
133
142
141
67
4.5
A90-2T4R8B
A90-2T8R0B
92
76/81
171
162
162
132
82
4.5
A90-2T010B
A90-4T1R5B
75
65
162
153
142
108
29
4.5
A90-4T2R5B
75
65
142
133
142
141
67
4.5
A90-4T4R2B
A90-4T5R6B
92
76/81
171
162
162
132
82
4.5
A90-4T9R4B
A90-4T013B
109
94/99
218
208
207
153
102
5.5
A90-4T017B
A90-4T025B
130
107/119
261
250
250
163
128
5.5
A90-4T032B
A90-4T038B
190
167/177
293
282
280
180
143
6
