User Manual of A90 Series Inverter
67
frequency sources
F00.13
Analog adjustment of
synthetic frequency
0: synthetic frequency of main
and auxiliary channels
1: AI1 * synthetic frequency of
main and auxiliary channels
2: AI2 * synthetic frequency of
main and auxiliary channels
0
○
F00.14
Acceleration time 1
0.00~650.00 (F15.13=0)
0.0~6,500.0 (F15.13=1)
0~65,000 (F15.13=2)
s
15.00
●
F00.15
Deceleration time 1
0.00~650.00 (F15.13=0)
0.0~6,500.0 (F15.13=1)
0~65,000 (F15.13=2)
s
15.00
●
F00.16
Maximum frequency
1.00~600.00
Hz
50.00
○
F00.17
Options of upper
frequency limit
control
0: set by F00.18
1: AI1
2: AI2
3: retention
4: VP (keyboard potentiometer)
5: retention
6: percent setting of upper limit
frequency communication
7: direct setting of upper limit
frequency communication
0
○
F00.18
Upper frequency limit
Lower frequency limit F00.19 to
maximum frequency F00.16
Hz
50.00
●
F00.19
Lower frequency limit
0.00 to upper frequency limit
F00.18
Hz
0.00
●
F00.20
Running direction
0: consistent direction
1: opposite direction
0
●
F00.21
Reverse control
0: Allow forward/reverse running
1: Prohibit reversing
0
○
F00.22
Duration of forward
and reverse dead zone
0.00~650.00
s
0.00
●
F00.23
Carrier frequency
1.0~16.0
(A90-4T1R5~A90-4T9R4B)
1.0~10.0
(A90-4T013B~A90-4T017B)
1.0~8.0
(A90-4T025B~A90-4T110B)
1.0~6.0 (A90-4T150~A90-4T304)
kHz
Model
Confirm
●
F00.24
Automatic adjustment
of carrier frequency
0: Invalid
1: valid 1
1
○
