User Manual of A90 Series Inverter
73
F02.31
Options of analog
input function
Ones place:
AI1
0: analog input
1: digital input (0 below 1V, 1
above 3V, the same as last time
under 1-3V)
Tens place:
AI2
0: analog input
1: digital input (the same as
above)
0000D
○
F02.32
Options of analog
input curve
Ones place:
Options of AI1 curve
0: curve 1
1: curve 2
2: curve 3
3: curve 4
Tens place:
AI2 curve selection
0: curve 1
1: curve 2
2: curve 3
3: curve 4
Hundreds place:
Reserved
Thousands place:
VP curve
selection: the same parameter
setting range as AI1
3010D
○
F02.33
Minimum input of
curve 1
0.00~F02.35
V
0.10
●
F02.34
Minimum input
setting of curve 1
–100.0~+100.0
%
0.0
●
F02.35
Maximum input of
curve 1
F02.33~10.00
V
9.90
●
F02.36
Maximum input
setting of curve 1
–100.0~+100.0
%
100.0
●
F02.37
Minimum input of
curve 2
-10.00~F02.39
V
0.10
●
F02.38
Minimum input
setting of curve 2
–100.0~+100.0
%
0.0
●
F02.39
Maximum input of
curve 2
F02.37~10.00
V
9.90
●
F02.40
Maximum input
setting of curve 2
–100.0~+100.0
%
100.0
●
F02.41
Minimum input of
curve 3
0.00~F02.43
V
0.10
●
F02.42
Minimum input
setting of curve 3
–100.0~+100.0
%
0.0
●
