User Manual of A90 Series Inverter
81
F05.18
Flux compensation
gain of synchronous
motor
0.00~500.00
%
0.00
●
F05.19
Filtering time
constant of flux
compensation of
synchronous motor
0.00~10.00
s
0.50
●
F05.20
Change rate of VF
separate power
supply setting
–50.00~50.00
%
0.00
●
F06
Vector control parameter group
F06.00
Speed proportional
gain ASR_P1
0.00-100.00
12.00
●
F06.01
Speed integral time
constant
ASR_T1
0.000-30.000
0.000: no integral
s
0.200
●
F06.02
Speed proportional
gain
ASR_P2
0.00-100.00
8.00
●
F06.03
Speed integral time
constant
ASR_T2
0.000-30.000
0.000: no integral
s
0.300
●
F06.04
Switching frequency
1
0.00 to switching frequency 2
Hz
5.00
●
F06.05
Switching frequency
2
Switching frequency 1 to
maximum frequency F00.16
Hz
10.00
●
F06.06
Separation threshold
of speed loop integral
0.000-1.000
0.500
F06.07
Filtering time
constant of speed
loop output
0.000~0.100
s
0.001
●
F06.08
Vector control slip
gain
50.00~200.00
%
100.00
●
F06.09
Upper limit source
selection of speed
control torque
0: set by F06.10 and F06.11
1: AI1
2: AI2
0
○
F06.10
Upper limit of speed
control motor torque
0.0~250.0
%
165.0
●
F06.11
Upper limit of speed
control brake torque
0.0~250.0
%
165.0
●
F06.12
Excitation current
proportional gain
ACR-P1
0.00~100.00
0.50
●
