User Manual of A90 Series Inverter
283
12.3.4 Register address distribution
Table 0-2 Detailed Definition of Register Address of MODBUS Protocol
Address Space
Note
Function code
0000H - 6F63H
For the function code FXX.YY, the high order is hexadecimal of
XX and the low order is hexadecimal of YY. For example, the
address of F00.14 is 000EH (00D=00H, 14D=0EH).
Function code (not saved
after power-down)
8000H-EF63H
When the parameters are set with the function code 0x06 or
0x10, the function that “the settings are valid immediately and
not saved after power-down” can be realized in the form of
“original address +8000H”. For example, the corresponding
address of F00.14 is 800EH (=000EH+8000H).
Control
comman
d (
write
only
)
7000H
~
71FFH
7000H control
word
0000H
Invalid command
0001H
Forward running
0002H
Reverse running
0003H
JOG forward
0004H
JOG reverse
0005H
Deceleration to stop
0006H
Stop the controller quickly
0007H
Free stop
0008H
Fault resetting
0009H
+/- input switching
000BH
JOG stop
Others to 00FFH
Reserved
7001H
Communication
percentage setting
of main channel
frequency A
-100.00% to 100.00% (100% = maximum
frequency)
7002H
Communication
percentage setting
of auxiliary
channel frequency
B
-100.00% to 100.00% (100% = maximum
frequency)
7003H
Torque
communication
setting
-200.00% to 200.00% (100% = digital
torque setting)
7004H
Communication
setting of process
PID setting
-100.00% - 100.00%
7005H
Communication
setting of process
PID feedback
-100.00% - 100.00%
7006H
Voltage setting of
0.00% to 100.00% (digital setting reference)
