User Manual of A90 Series Inverter
74
F02.43
Input of inflection
point 1 of curve 3
F02.41~F02.45
V
2.50
●
F02.44
Input setting of
inflection point 1 of
curve 3
–100.0~+100.0
%
25.0
●
F02.45
Input of inflection
point 2 of curve 3
F02.43~F02.47
V
7.50
●
F02.46
Input setting of
inflection point 2 of
curve 3
–100.0~+100.0
%
75.0
●
F02.47
Maximum input of
curve 3
F02.45~10.00
V
9.90
●
F02.48
Maximum input
setting of curve 3
–100.0~+100.0
%
100.0
●
F02.49
Minimum input of
curve 4
-10.00~F02.51
V
0.1
●
F02.50
Minimum input
setting of curve 4
–100.0~+100.0
%
0
●
F02.51
Input of inflection
point 1 of curve 4
F02.49~F02.53
V
2.50
●
F02.52
Input setting of
inflection point 1 of
curve 4
–100.0~+100.0
%
25.0
●
F02.53
Input of inflection
point 2 of curve 4
F02.51~F02.55
V
7.50
●
F02.54
Input setting of
inflection point 2 of
curve 4
–100.0~+100.0
%
75.0
●
F02.55
Maximum input of
curve 4
F02.53~10.00
V
8.80
●
F02.56
Maximum input
setting of curve 4
–100.0~+100.0
%
100.0
●
F02.57
AI1 filtering time
0.00~10.00
s
0.10
●
F02.58
AI2 filtering time
0.00~10.00
s
0.10
●
F02.60
VP filtering time
0.00~10.00
s
0.10
●
F02.61
AD sampling
hysteresis
2~50
2
○
F03
Output terminal function group
F03.00
Options of Y1 output
function
0: no output
1: inverter running (RUN)
2: up to output frequency (FAR)
3: output frequency detection
FDT1
1
○
F03.02
Options of R1 output
function
(EA-EB-EC)
7
○
