10
TO
REMOVE
AND
REPLACE
THE
SEWING
HOOK
Remove
bobbin
case
cap
and
bobbin
as
in¬
structed
on
page
4.
Remove
the
hook
gib
screw
V2,
Fig.
24
and
swing
back
the
gib
to
allow
base
of
bob¬
bin
case
to
be
taken
out.
Remove
screw
W2
from
the
center
of
the
hook.
Tap
hook
slightly
on
the
bottom
of
its
rim
to
force
it
from
its
socket.
Do
not
try
to
pry
it
out,
as
prying
may
b^nd
the
shank
of
the
hook.
I
When
replacing
hook,
be
sure
the
prongs
of
the
shank
enter
thelslot
at
the
bottom
of
the
socket,
*
>
otherwise
the
hook
will
be
out
of
time.
Then
replace
and
tighten
screw
W2.
Fig.
24
NEEDLE
GUARD
The
function
of
the
needle
guard
X2
is
to
pre¬
vent
the
point
of
the
hook
from
striking
the
needle,
if,
when
passing
through
the
material,
the
needle
is
de¬
flected
toward
the
hook.
The
upright
portion
of
the
needle
guard
should
be
sprung
with
a
screwdriver
until
it
prevents
the
hook
point
from
striking
the
needle.
It
should
not,
however,
be
sprung
out
enough
to
deflect
the
needle
from
its
normal
path.
TO
REMOVE
AND
REPLACE
THE
ROLLER
PRESSER
DRIVING
BELT
(UPPER)
Raise
roller
presser.
Remove
clamping
nut
K2,
Fig.
2).
Remove
arm
top
cover
and
face
plate.
Remove
adjusting
rod
C
by
lifting
rod
up
and
out
of
socket
D.
Slip
belt
off
spreader
cone
E.
Raise
idler
pulley
bracket
F,
insert
a
screwdriver
in
between
re¬
taining
rings
G
and
spindle
H,
then
twist
the
screw¬
driver
and
the
rings
will
snap
out.
With
a
brass
drift
pin,
tap
spindle
H
free
of
bracket
F,
this
will
release
i^l»r
mil
levs
J
and
the
belt
can
be
removed.
To
replace,
slip
belt
M
into
belt
pulley
of
roller
presser
K,
up
under
idler
pulley
bracket
F
and
over
spreader
cone
E.
Insert
spindle
H
through
bracket
F
and
pulleys
J,
being
certain
that
the
pulleys
are
under
belt
M.
Slip
retaining
rings
G
into
position
and,
with
a
screwdriver,
push
rings
until
they
snap
into
the
spindle
slot.
Insert
spring
end
of
adjusting
rod
C
into
hole
N,
then
push
rod
C
up
and
slip
its
lower
end
into
socket
D.
Adjust
belt
tension
by
turning
nut
P
counterclockwise
to
increase
tension
or
clockwise
to
decrease
tension.
Replace
face
plate,
arm
top
cover
and
clamping
nut.
