Singer 4432 User Manual

Connect the machine to a power source as illustrated. (1)
This appliance is equipped with a polarized plug which must be
used with the appropriate polarized outlet. (2)
Unplug power cord when machine is not in use.
The foot control pedal regulates the sewing speed. (3)
Consult a qualified electrician if in doubt of how to connect
machine to power source.
Unplug power cord when machine is not in use.
The foot control must be used with the appliance by FC-
1902A (110-120V area)/ FC-2902A (220-240V area)/ 4C-
316Q (110-125V area).
Press main switch (A) to"l"forpower and light.
For appliance with a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to fit in a polarized outlet only one way. If it does not
fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician to install the proper outlet. Do
not modify the plug in any way.
Attention:
Foot control
Attention:
Sewing light
IMPORTANT NOTICE
a. Polarized attachment plug
b. Conductor intended to be grounded
23
6
1
A
Connecting Machine to Power Source
EN
a
b

Singer 4432 Specifications

General

Stitch Applications	110
Built-in Stitches	32
Buttonhole Style	1-step
Presser Foot Lifter	Extra High
Needle Positions	3
Free Arm	Yes
Heavy Duty Metal Frame	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Type	Mechanical
Stitch Width	6mm
Adjustable Presser Foot Pressure	Yes
Model	4432
Stitch Length	4mm
Buttonhole Styles	1
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Button Sewing Foot
Motor	60% stronger motor
Voltage	120V
Maximum Sewing Speed	1100 stitches/minute
Warranty	25-year limited warranty
