Singer 4432 User Manual

Winding the Bobbin
EN
12
- Place thread and corresponding spool holder on to spool
pin. (1/2)
- Snap thread into thread guide. (3)
- Wind thread clockwise around bobbin winder tension discs. (4)
- Thread bobbin as illustrated and place on spindle. (5)
- Push bobbin spindle to right. (6)
- Hold thread end securily. (7)
- Step on foot control pedal. (8)
- Trim thread close to the bobbin & then continue winding
until bobbin is full. (9)
- Cut thread, push bobbin spindle to left (10) and remove.
When the bobbin winder spindle is in "bobbin winding"
position, the machine will not sew and the .
To start sewing, push the bobbin winder spindle to the left
(sewing position).
Please Note:
handwheel turn
1
2
4
7
8
9
5
6
3
10

Singer 4432 Specifications

General

Stitch Applications	110
Built-in Stitches	32
Buttonhole Style	1-step
Presser Foot Lifter	Extra High
Needle Positions	3
Free Arm	Yes
Heavy Duty Metal Frame	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Type	Mechanical
Stitch Width	6mm
Adjustable Presser Foot Pressure	Yes
Model	4432
Stitch Length	4mm
Buttonhole Styles	1
Presser Feet	All-Purpose Foot, Zipper Foot, Buttonhole Foot, Button Sewing Foot
Motor	60% stronger motor
Voltage	120V
Maximum Sewing Speed	1100 stitches/minute
Warranty	25-year limited warranty
