Singer 7426 - Sec. 3 Adjustment of Feed Dog Height

- 12 -
Sec. 3 Adjustment of feed dog height
Checking:
1. Move feed dog to its highest position by turning hand wheel.
Check to see if feed dog height is as illustrated below.

Adjustment:
1. Remove needle plate. Loosen nut with wrench.
2. Adjust height by turning screw as illustrated. Tighten nut securely after adjustment..
0.9 – 1.0 mm
