Bobbin Winding
The spool pin is located in the back of the
sewing machine.Tilt out the spool pin.
Place the spool of thread on it.
The end of the thread should be coming out
from the spool as shown.
1 Spool pin
2 End of the thread
3 Spool of thread
Removing the bobbin
Slide the bobbin cover plate toward you and
remove it.
1 Bobbin cover plate
Lift out the bobbin from the bobbin holder.
2 Bobbin
5
