© Dec 2021 1-4 GTZZ14EJ&16EJ Operation Manual
MACHINE SPECIFICATIONS
Table 1-2 GTZZ16EJ specifications (continued)
MEASURE
AB16EJ (METRIC) AB520EJ (IMPERIAL)
Hydraulic system pressure 21 MPa 3045 Psi
Battery (number×voltage, capacity) 8×6V, 420Ah
System voltage
12 VDC
Control voltage 12 VDC
GROUND BEARING DATA
Max tire load
3760 kg
8289 lb
Tire contact pressure
740.1 715 KPa
103.7 psi
ENVIRONMENT REQUIREMENT
Max allowable wind speed 12.5 m/s 28 mph
Max allowable altitude 1000 m 3280 ft
Allowable ambient temperature
(lead-acid battery)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium battery)
-20℃～40℃ -4℉～104℉
Max allowable RH 90%
Storage environment
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (20℃ [68℉]), and away from rain, sun, corrosive
gas,inflammables and explosives.
WEIGHT
Gross weight (unladen) 7300 kg
16094 lb
Note:
a) The working height adds 2m (6ft 7in) of human height to platform height。
b) The ground bearing data is approximate value, not factoring the different options, thus it serves only in adequately safe
conditions
c) In different areas, hydraulic oil, engine oil, coolant, fuel and lubrication should be added in accordance with the
environmental temperature.
d) In cold weather, auxiliary devices are needed to start the machines.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
