I. SCRAPPING
IMPORTANT!
In the case of scrapping, all the parts of the device will have to be disposed of
through adequate disposal channels by applicable legislation. Before scrapping,
all plastic and rubber parts will have to be separated from the electrical material.
Parts made of plastic, aluminum, and steel only may be recycled if collected by
special centers.
3. Contents of Powder Handling Station packaging
I
IV
III
II
V
V
III
IV
VI
ZONE I
x1
x2
x8
BOX OF
ACCESSORIES
FOR PHS
ZONE II
ZONE VI
POWDER HANDLING STATION
INSTRUKCJA OBSŁUGI
Przed użyciem urządzenia należy przeczytać instrukcję obsługi.
G
I
J
E
D
F
H
K
Zone I: Components of the Metal shelf with screws
13
, Power cable.
Zone II: PHS User manual, Anti-noise headphones, Box with additional accessories:
D
Powder Wiper,
E
Tube brush,
F
Service wrench
17/10,
G
Allen key Hex 5mm,
H
General-purpose nozzle,
I
Powder suction nozzle form cake,
J
Gap nozzle,
K
PVC brush.
Zone III: Spare Metal container with lid.
Zone IV: Suction hose with Suction Handle
4
.
Zone V: Additional Powder Chamber grid (for cleaning small parts).
Zone VI: Components of the Slope ramp
A
.
11 | POWDER HANDLING STATION Manual
