Sintrol Snifter mA - Page 9

Snifter mA+ EX RF User Manual 9
·
Adjustable from 0 – 6000 s
Alarm delay time
• Default at factory, 30 s
• Adjustable from 0 – 60 000 s
Alarm hysteresis time
• Default at factory, 0s
• Adjustable from 0 – 25 s
Process Conditions
Temperature Max 250 °C
Pressure Max 200 kPa
Gas Velocity Min 3 m/s
Humidity Max 95 % RH (non-condensing)
Ambient Conditions
Staring temperature -20...+40 °C
Running temperature -40...+60 °C
Humidity Max 95 % RH (non-condensing)
Materials and Weight
Probe (wetted part) Stainless steel (AISI 316L)
Process Connection (wetted part) Stainless steel (AISI 316L)
Enclosure Aluminum
Probe Insulation (wetted part) PEEK
Weight 0.6 kg
Table 2 Technical specification
