Form ZCE873 4 Date 2023October3/A
HOSE AND HOSE CONNECTIONS
The air supply hose recommended is 3/8" (10mm) I.D. If an extension hose is necessary, use 1/2” (13mm) ID hose with couplings not less than 3/8" (10mm) I.D.
LUBRICATION
All models may operate without airline lubrication. However, operating the tool without airline lubrication may reduce tool performance and vane life.
If an airline lubrication is not used, it is recommended that the tool be oiled daily before use to improve performance. Add 2-4 drops of air motor oil and
run the tool for 10-20 seconds to distribute oil through the tool.
For maximum performance and tool life, an air line lubricator, set to deliver 2 drops per minute, is recommended. SIOUX No. 288 Air Motor Oil is
recommended.
MAINTENANCE
Water, dust and other airline contaminants can cause rust and vane sticking. For long periods between tool use, flush the tool with a few drops of oil
and run for 10 seconds. This will help remove contaminants and reduce the formation of rust.
OPERATION
The die grinder operates in the clockwise direction when viewed from the operator’s position.
The tool is equipped with a locking type lever in order to prevent accidental start-up.
Speed of the tool may be adjusted by turning the regulator, which is located opposite the throttle lever.
INSTALLING MOUNTED WHEELS
Insert the mounted wheel into the collet. Make sure the wheel shank and the collet size match. Do not allow the wheel to extend beyond the collet an
excessive distance.
Hold the collet body with a 9/16" (14mm) wrench and the collet nut with a 3/4" (19 mm) wrench.
Turn the collet nut to the right and firmly tighten the collet on to the wheel shank.
REMOVING MOUNTED WHEELS
To remove the mounted wheel, hold the collet body with a 9/16" (14 mm) wrench and the collet nut with a 3/4" (19 mm) wrench.
Turn the collet nut to the left and loosen the collet.
Remove the mounted wheel.
WARNING
Disconnect tool from air supply before installing or removing wheel or making any adjustments
To Next Page
