PART LIST
NO
DESCRIPTION
QTY.
NO DESCRIPTION QTY.
66 Switch 1 102 Feed-in roller 1
67 Nut 8 103/116 Retracting spring 3
68 Locking ring 1 104 Bearing bush 5
69 Flat washer 1 105 Rod 1
70 Chain wheel 1 106 Flat washer 24
71 Square sleeve 1 107 Ratchet 44
72 Gear wheel 1 108 Bolt 8
73 Retaining ring 1 109 Clamping device 2
74 Belt wheel 1 110 Knives 2
74-01 Pinion 1 111 Knife stalk 1
74-02 Lantern ring 1 111-1 Set screw 3
74-03 Needle bearing 2 111-2 Arbor 1
75 Wing,cpl. 1 112 Adjusting bolt 4
75.1 Joint 1 113 Needle bearing 1
75.2 Lantern ring 1 114 Bearing Cap 1
75.3 Short shaft 1 115 Sheet metal deflector 1
76 Retracting spring 1 117 Plastic pointer 1
76-1 Socket head bolt 1 118 Front table top 1
76-2 Hex nut 1 119 Sliding block 4
77 Arbor 1 120 Socket head bolt 4
78 Socket head bolt 2 121 Clasp 1
79 Locking washer 2 122 Arc cover 1
80 Flat washer 2 122-1 Pin 1
81 Chain wheel 2 123 Hand knob 1
82 Chain 1 124 Scale 1
83 Belt disk 1 125 Stud bolt 1
84 Set screw 2 126 Cover 1
85 Socket head bolt 3 127 Square tube 1
86 Flat belt 3 127-1 Cover 1
87 Supporting plate 1 128 Spacer 1
88 Pole 1 128-1 Locking ring 1
91 Motor belt wheel 1 128-2 Locking ring 1
92 Motor 1 129 Hand knob 1
93 Grooved ball bearing 1 130 Socket head bolt 2
94 Bearing cover 1 131 Limit Switch 1
95 Locking washer 3 132 Switch cover 1
96 Hex nut 3 132-1 Flat washer 4
97 Strut 1 132-2 Socket head bolt 4
98 Flat washer 2 133 Stud bolt 1
99 Socket head bolt 1 134 Impede stalk 1
100 Feed-out roller 1 134-1 Locking washer 1
101 Ratchet 3 134-2 Hex nut 1
