PART LIST
NO DESCRIPTION QTY. NO DESCRIPTION QTY.
1 Socket head bolt 4 35 Flat washer 1
2 Cord wrap 2 36 Flat washer 1
3 Side plate 1 37 Locking washer 1
3-1 Protecting hood 1 38 Hex nut 1
4 Socket head bolt 11 39 Hex nut 4
5 Locking washer 11 40 Rod, long 4
6 Underprop 4 41 Pan head screw 7
6-1 Hex nut 4 42 Cable Clamp 7
7 Motor covering 1 43 Rubber buffer 2
8 Pan head screw 1 44 Flat belt 1
9 Hex nut 1 45 Flat washer 4
10 Hex nut 1 46 Locking washer 4
11 Locking washer 1 47 Socket head bolt 4
12 Flat washer 6 48 Rod, long 2
13 Angle 1 48-1 Rod, long 2
14 Screw 1 49 Flat washer 12
15 Chain 1 50 Socket head bolt 4
16 Crank 1 51 Line 1
16.1 Joining 1 52 Plastic locknut 3
16.2 Upper cover 1 53 Strain relief 3
16.3 Nether cover 1 54 Nut 1
16.4 Screw 1 54-1 Adjusting washer 1
17 Plug 1 54-2 Spring 1
18 Threaded spindle, short 3 54-3 Rod 1
19 Table 1 54-4 Sleeve 1
19-1 Threaded spindle nut 4 54-5 Sign 1
19-2 Sleeve 4 54-6 Pan head screw 1
20 Pointer 1 55 Locking line 6
21 Flat washer 1 56 Rubber set 1
22 Locking washer 1 57 Power cable 1
23 Pan head screw 1 58 Protecting hood 1
24 Chain wheel 4 58-1 Tool box 1
25 Flat washer 4 58-2 Box cover 1
26 Locking washer 4 59 Switch box 1
27 Hex nut 4 59.1 Upper cover 1
28 Socket head bolt 4 59.2 Nether cover 1
29 Sleeve 4 60 Pan Head Self Tapping Screw 2
30 Socket head bolt 4 61 Thermo-protector 1
31 Side plate 1 62 Pan Head Self Tapping Screw 4
32 Scale for cutting depth 1 63 Pan Head Self Tapping Screw 3
33 Socket head bolt 1 64 Pan Head Self Tapping Screw 2
34 Locking washer 1 65 Terminal 4
