SIP DISC 220 F ALP User Manual

DISC
11
1.3 Technical data
Type DISC 220 F ALP
Working width 2159 mm
Weight 415 kg
Transport width 2217 mm
Cardan shaft rotation
(max.)
1000 (ISO) rpm
1000 (DIN) rpm
540 (ISO) rpm
540 (DIN) rpm
Disc rotation 3000 rpm
Safety clutch (Nm) 800
Number of discs 5
Number of blades 10
Tractor power (min.) 30 kW
Working speed up to 18 km/h
Mowing capacity 2,5 ha/h
Swath width 0,9 – 1,2 mm
Connector type three-point
Type DISC 260 F ALP
Working width 2572 mm
Weight 460 kg
Transport width 2630 mm
Cardan shaft rotation
(max.)
1000 (ISO) rpm
1000 (DIN) rpm
540 (ISO) rpm
540 (DIN) rpm
Disc rotation 3000 rpm
Safety clutch (Nm) 800
Number of discs 6
Number of blades 12
Tractor power (min.) 38 kW
Working speed up to 18 km/h
Mowing capacity 3 ha/h
Swath width 1 – 1,5 mm
Connector type three-point

SIP DISC 220 F ALP Specifications

General

Brand	SIP
Model	DISC 220 F ALP
Category	Farm Equipment
Language	English
