When using your mig welder, basic safety precautions should always be followed to
reduce the risk of personal injury and / or damage to the mig welder.
Read all of these instructions before operating the mig welder and save this user man-
ual for future reference.
The mig welder should not be modified or used for any application other than that for
which it was designed.
This mig welder was designed to supply electric current for MIG welding.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before each use of the mig welder always check no parts are broken and that no
parts are missing.
Always operate the mig welder safely and correctly.
KNOW YOUR MIG WELDER: Read and understand the owner's manual and labels af-
fixed to the mig welder. Learn its applications and limitations, as well as the potential
hazards specific to it.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work benches and dark areas invite
accidents. Floors must not be slippery due to oil, water or sawdust etc.
DO NOT USE THE MIG WELDER IN DANGEROUS ENVIRONMENTS: Do not use the mig
welder in damp or wet locations, or expose it to rain. Provide adequate space sur-
rounding the work area. Do not use in environments with a potentially explosive atmos-
phere.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the mig
welder.
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
33
PARTS LIST WELDMATE T166 MIG
Ref. No. Description Sip Part No. Ref. No. Description Sip Part No.
1. Left side panel WE02-00035 21. Fan support WE02-00022
2. Hinge WE02-00051 22. Fan motor WE02-00023
3. Lock WE02-00002 23. Fan Blade WE02-00024
4. Wire feed motor WE02-00036 24. Right side panel WE02-00055
5. Front panel WE02-00003 25. Handle WE02-00015
6. Rotary switch 6pos WE02-00052 26. Mains lead WE02-00056
7. On/Off switch WE02-00004 27. Rear panel WE02-00057
8. Thermal overload light WE02-00053 28A. Gas hose connector WE02-00042
9. Potentiometer knob WE02-00007 28B. Gas valve connector WE02-00043
10. Welding torch 02741 29. Rectifier WE02-00058
11. Earth return lead WE02-00010 30. Rectifier support WE02-00059
12. Cable grommet WE02-00009 31. Breaker WE02-00020
13. Cable clamp WE02-00011 32. Auxiliary transformer WE02-00031
14. PCB holder WE02-00013 33. Centre panel WE02-00046
15. PCB WE02-00037 34. Positive terminal WE02-00047
16. Foot WE02-00019 35. Wire spool holder WE02-00030
17. Lower panel WE02-00038 36. Negative terminal WE02-00048
18. Mains filter WE02-00016 37. Fuse WE02-00032
19. Thermostat WE01-00039 N/A. Wire feed roller 0.6-0.8 WE02-00049
20. Transformer c/w choke WE02-00054
To Next Page
