38
•Pickup Truck:
1. Use a blunt plastic putty knife or similar blunt tool to lift the
rubber molding around the windshield and tuck the antenna cable
underneath it.
2. Continue tucking the cable underneath the windshield molding
around the windshield to the lowest corner.
3. At the lowest corner of the windshield, route the cable out of the
windshield molding and into the rubber weather stripping around the
door opening. Lift the weather stripping from the opening and tuck
the cable inside it, then replace the weather stripping. Run the cable
inside of the weather stripping to the bottom of the door opening.
4. Pull the cable out of the weather stripping at the bottom of the door
opening and route it under the carpet toward the dashboard. Coil any
excess cable in a hidden location, such as under the carpet, keeping
it away from any vehicle pedals or controls. Secure the excess cable
with wire ties.
5. Bring the end of the cable out at
the PowerConnect Vehicle Dock
location. Leave yourself enough
cable so you can easily connect it
to the antenna connector of dock.
6. Continue with “Step 5: Connect
the Magnetic Mount Antenna and
PowerConnect Power Adapter” on
page 39.
Vehicle Installation
