62 07 687 D3530
10 D3530.201.01.06.02 07.2011
3 Unit description Sirona Dental Systems GmbH
3.1 Standards/Approvals Operating Instructions LEDview / LEDview S
3
Unit description
Unit description
3.1
Standards/Approvals
Standards /Approvals
The LEDview / LEDview S operating light complies with the following
standards (the list below is not exhaustive):
● IEC 60601-1 (electrical and mechanical safety)
● IEC 60601-1-2 (electromagnetic compatibility)
● ISO 9680 (Operating light
1
)
Unit model: In connection with the treatment centers approved for this
purpose, this product complies with the provisions of Council Directive 93/
42/EEC of June 14, 1993 concerning medical devices.
Ceiling model / Ceiling combination: The LEDview / LEDview S bears the
CE mark in compliance with the provisions of Council Directive 93/42/
EEC of June 14, 1993 concerning medical devices.
3.2
Technical Data
Technical Data
LEDview
1. No defined method of measuring the color rendering index currently exists for
the LED technology used. (cf.Technical Report CIE 177:2007.) The normatively
required color temperature of < 6300 K can be attained only with the optional filter
disk. A comparison of dental colors is possible only to a limited extent.
Model designation: LEDview
Light source: 4 light-emitting diodes
Illuminance: adjustable from < 8,000 lux to > 27,000 lux
acc. to ISO 9680
Lighting control: Electronic brightness control, composite
function
Color temperature: 5,700 K – 6,900 K
with optional filter disk: 5,100 K – 5,700 K
Unit model power
connection:
Electrical supply via the treatment center
Line voltage for ceiling
models:
230 V 50 Hz
115, 100 V 60 Hz
Nominal current for
ceiling models:
for 230 V 0.1 A
for 115 V 0.2 A
for 100V 0.23A
Overvoltage category: 2 acc to. IEC 60664-1
Power consumption of
operating light:
< 20 W
Protection class: The unit supplying power corresponds to
protection class I
Degree of protection
against ingress of water:
Ordinary equipment (IPX 0 – without
protection against ingress of water)
