62 07 687 D3530
22 D3530.201.01.06.02 07.2011
4 Operation Sirona Dental Systems GmbH
4.3 Positioning the light field Operating Instructions LEDview / LEDview S
4.3
Positioning the light field
Position ing the li ght field
The LEDview / LEDview S enables you to adjust the light field in a way
that optimally supports viewing of areas of the mouth which are difficult to
access.
Tip: The ideal working distance between the light and the patient's mouth
is 70 cm.
Rotate LEDview / LEDview S
Incline LEDview / LEDview S sideways
Tilt LEDview / LEDview S
CAUTION
The light field must be readjusted depending on the treatment position.
The patient and user can be blinded.
➢ Position the light so that neither the patient nor the user can be
blinded.
