62 07 687 D3530
12 D3530.201.01.06.02 07.2011
3 Unit description Sirona Dental Systems GmbH
3.2 Technical Data Operating Instructions LEDview / LEDview S
LEDview S
Model designation: LEDview S
Light source: 4 light-emitting diodes
Illuminance: adjustable, 2 levels:
- Composite < 8,000 lux
- normal mode in delivery condition:
> 23,000 lux
- normal mode at maximum brightness
1
:
> 27,000 lux
1. The brightness can be set by the service engineer.
Lighting control: switchable, 2 brightness levels
Color temperature: 5,700 K – 6,900 K
with optional filter disk: 5,100 K – 5,700 K
Unit model power
connection:
Electrical supply via the treatment center
Overvoltage category: 2 acc to. IEC 60664-1
Power consumption of
operating light:
< 20 W
Protection class: The unit supplying power corresponds to
protection class I
Degree of protection
against ingress of water:
Ordinary equipment (IPX 0 – without
protection against ingress of water)
Mode of operation: Continuous operation
Transport and storage
conditions:
Temperature: -40° C – +70° C
(-40° F –158° F)
Relative humidity: 10% – 95%
Barometric pressure: 500 hPa – 1,060 hPa
Operating conditions: Ambient temperature: 10°C – 40°C
(50°F – 104°F)
Relative humidity: 30% – 85%
no condensation
Barometric pressure: 700 hPa – 1,060 hPa
Installation site: ≤ 3,000 m above sea level
Pollution degree: 2 acc. to IEC 60664-1
Year of manufacture:
Unit model: On the type plate of the
treatment center
Dimensions of light
crown:
