Sirona XIOS XG User Manual

64 09 713 D3610
18 D3610.201.01.08.02 09.2016
3System description Sirona Dental Systems GmbH
3.5Sensor holder systems Operating Instructions and Installation XIOS XG USB module and sensors
3.5.2 Aimright reusable sensor holder system
There are different sensor holders available depending on the type of
exposure. The sensor holders are color-coded.
The same localizer ring is used for all sensor holders.
The sensor holders are available for sensor sizes 1 and 2.
A Localizer ring
B Sensor holder for posterior tooth exposures right upper jaw /
left lower jaw, yellow
C Sensor holder for bite wing exposures, red
D Blue for anterior tooth exposures, blue
E Sensor holder for posterior tooth exposures left upper jaw /
right lower jaw, yellow
