WARNING!
Risk of injury from falling speakers that were inadequately secured!
If speakers are not properly secured when mounted, they can cause severe injury
and considerable damage by falling.
Always secure portable sound systems (speakers) with two independent safety
devices, such as safety cables.
1. Screw the ring eye into the top of the speaker.
2. Thread the wire rope through the ring eye and the ceiling suspension.
3. Lock the wire rope with two snap hooks.
4. Attach the cables of the speaker to the wire rope with suitable cable ties.
Ceiling installation
Installation
12
Drop 4, drop 6, drop 8
Passive Speaker
