LED Description
LED Color Description
WLAN Blue
Lights up in Blue when WLAN is enabled. Blinks when OPS is
active.
Power Orange Lights up when powered ON. Blinks on TEST/RESET.
Signal White
This LED shows the quality of the signal it receives from your
Router/Access Point.
0-25%: 250 milliseconds ON – 250 millisecond OFF
25-50%: 1000 milliseconds ON – 1000 milliseconds OFF
50-100%: Continuous ON
LAN Green Lights up when a LAN cable is connected.
