5
Note: For the location of signs and symbols on the machine, see drawing on pg. 8-9.
13) Recommends working with suitable
clothing and/or protection during assembly,
use, maintenance and repair.
12) Indicates a greasing point.
14) OPEN-CLOSED CIRCUIT
(See page 47).
Explains how to choose the circuit to be used,
depending on that installed in the tractor used.
15) CONTROL BOARD
(See pages 42,44,46,48,50,52,61,63,68,70,72).
Explains the various operations that can be
