LEVEL THE GAME SIDE TO SIDE USING THE LEVELING GLIDES.
RELOCATE THE BALL COUNT SWITCH MOUNTING BRACKET BY
REMOVING THE TWO
l/4
X 20 X 1" MACHINE BOLTS FROM THE
BALL COUNT SWITCH MOUNTING BRACKET WHICH HOLDS THE
BRACKET TO THE FRONT BULKHEAD OF THE REAR CABINET IN THE
~0
SCORE FLOOR AREA. DO NOT UNPLUG THE CONNECTOR
LEADING FROM THE WIRE HARNESS TO THE BALL COUNT SWITCH.
AFTER THE TWO MACHINE BOLTS ARE REMOVED, SIMPLY TURN THE
BRACKET AROUND AND REINSTALL THE BOLTS THROUGH THE
SWITCH MOUNTING BRACKET AND BACK INTO THE PRE-TAPPED
HOLES IN THE FRONT BULKHEAD OF THE REAR CABINET.
ADJUST
THE ACTUATING WIRE OF THE SWITCH SO THAT THE BALLS
STRIKE THE WIRE AS THEY PASS THROUGH THE BALL RETURN
OUTLET.
REFER TO DRAWING NO. 600035 IN BACK OF MANUAL.
THE FRONT AND SIDE CAGE PIECES ARE PACKED IN A SEPARATE
BOX.
THE CAGE ASSEMBLY CONSISTS OF THREE PARTS: FRONT
CAGE,
LEFT CAGE AND RIGHT CAGE. PLACE RIGHT CAGE ON
ALLEY SO THAT IT FITS INTO THE RECESSED CUT ON THE RIGHT
SIDE OF THE REAR CABINET.
<<NOTE>> WHEN INSTALLING SIDE NETS, TAKE CARE NOT TO
SCRATCH THE PLASTIC CHANNEL COVERS WITH THE END
OF THE NETS.
SECURE IN PLACE USING SIX
#8
SCREWS AND WASHERS
PROVIDED.
REPEAT THIS PROCEDURE ON THE OTHER SIDE.
THE
FRONT CAGE FITS ON THE SIDE CAGE AND IS TO BE SECURED
USING THE FOUR KNURLED SCREWS PROVIDED.
UNLOCK THE TICKET TRAY ACCESS PANEL ON THE FRONT LEFT
SIDE OF THE ALLEY AND REMOVE. FILL THE TICKET TRAY WITH
TWO STACKS OF TICKETS INTO THE TRAY. CONNECT THE WIRE
HARNESS FOR THE LOW TICKET INDICATOR SWITCH TO THE
RECEPTACLE UNDER THE ACCESS PANEL AND PLACE THE TICKET
TRAY IN PLACE IN THE GROOVES IN THE ALLEY.
SEE
SECTION C FOR TICKET LOADING INSTRUCTIONS.
UNLOCK COIN BOX DOOR AND PLACE COIN BOX IN ALLEY.
SHUT
AND LOCK DOOR.
OFTEN IN SHIPMENT, THE LAMPS IN THE BACK CABINET MAY
LOOSEN IN THEIR SOCKETS. MAKE SURE ALL ARE TIGHT PRIOR
TO POWERING UP THE ALLEY.
INSTALL FIVE BALLS INTO THE ALLEY. ALLEY WILL WORK WITH
ANY NUMBER OF BALLS FROM ONLY ONE TO SEVEN MAXIMUM.
PLUG WIRE INTO PROPERLY WIRED 120V AC RECEPTACLE AND
VERIFY ALL LAMPS ARE LIT. THE GAME IS READY TO PLAY.
C.
TICKET DISPENSER
1.
BASIC ELECTRONIC OPERATION OF TICKET DISPENSER MODEL
DL1275H:
WHEN THE CONTROL UNIT CALLS FOR A TICKET TO BE
ISSUED, THE MOTOR IN THE DISPENSER IS TURNED ON. WHEN A
TICKET IS DISPENSED, THE
OPT0
BEAM BREAKER SENSES A
NOTCH IN THE TICKET AND SENDS BACK A SIGNAL TO THE
CONTROL UNIT.
AT THIS TIME THE TICKET COUNTER IS
INCREMENTED.
IF NO MORE TICKETS ARE CALLED FOR THE
MOTOR IS TURNED OFF.
