Skee Ball Lightning - Unpacking Instructions; Standard Alley Assembly

A. UNPACKING INSTRUCTIONS
REMOVE ALL PARTS FROM THE SHIPPING BOXES OR CRATES. AN
INVENTORY OF THE PARTS SHOULD INCLUDE THE FOLLOWING:
1. BACK CABINET ASSEMBLY.
2.
RUNWAY ASSEMBLY.
3.
l/4-20 UNC X 2.00 LG. HEX HEAD BOLTS (QTY. 2)
4. l/4 FLAT WASHER (Q'l'Y. 2)
5.
i/4-20 UNC NUTS
(QTY. 2)
6. TICKET TRAY ASSEMBLY (1F EQUIPPED).
' I.
RIGHT SIDE CAGE.
a.
LEFT SIDE CAGE.
9. FRONT CAGE.
10. 8-32 UNC X .30 LG.
BUTTON HEAD SCREWS (QTY. 121
11. #El FLAT WASHERS (QTY. 12)
12. X8 KNURLED HEAD SCREW (QTY. 4).
13. MANUAL 990017 SKEE-BALL LIGHTNING INSTALLATION AND
OPERATION.
14.
MANUAL 990007 TICKET DISPENSER MANUAL (IF EQUIPPED).
15. LEVELING GLIDES (QTY. 6)
16. GAME COST STICKERS.
17. COIN BOX
18. BALLS (QTY. 5)
IF ANY OF THE ABOVE ITEMS ARE MISSING, PLEASE CONTACT YOUR
SALESPERSON IMMEDIATELY.
B. STANDARD ALLEY ASSEMBLY.
1. FRONT RUNWAYS AND BACK CABINETS NEED NOT BE MATCHED.
2. INSTALL FOUR (41 LEVELING GLIDES ON THE BOTTOM OF THE
REAR CABINET AND TURN THEM ALL THE WAY IN.
3.
INSTALL TWO (2) LEVELING GLIDES ON THE BOTTOM OF THE
RUNWAY IN THE TWO HOLES NEAR THE REAR CABINET END OF THE
UNIT.
4.
PLACE THE REAR CABINET AND THE RUNWAY IN THEIR
APPROXIMATE FINAL POSITION LEAVING A 12" GA@ BETWEEN
THEM. CAREFULLY LOOSEN THE CABLE TIE IN THE REAR
CABINET AND CONNECT SIX (6) JUNCTION PLUGS (24 PIN, 1
PIN, 6 PIN, 3 PIN AND ROPE LIGHT PLUG 2 PLCS.).,
5. BUTT THE REAR CABINET AND THE RUNWAY TOGETHER. PLACE
THE l/4-20 FLAT WASHER ONTO THE BOLT AND INSERT THEM
INTO THE HOLES ON EITHER SIDE OF THE BACK CABINET.
THEY
WILL THREAD INTO THE T-NUTS LOCATED ON THE RUNWAY.
THESE BOLTS SHOULD THEN BE HAND TIGHTENED TO KEEP THE
BACK CABINET AND RUNWAY ALIGNED.
***CAUTION*** THESE BOLTS AND THE BALL COUNT SWITCH
SHOULD BE REMOVED BEFORE MOVING THE ALLEY.
THE ALLEY
SHOULD BE MOVED IN TWO PIECES UNLESS IT IS PLACED ON
DOLLIES.
2
