Skee Ball Lightning - General Troubleshooting Guide

THE 'AUXl' BUTTON WILL CYCLE THRU YOUR CHOICES (Y AND N). TO
ACCEPT THE DEFAULT SETTINGS, PRESS THE 'START' BUTTON WHEN
THE DISPLAY READS:
DEFAULTS: Y
TO CHANGE FROM THE DEFAULT SETTINGS, PRESS THE 'AUXZ' BUTTON.
THE DISPLAY WILL THEN GO ON TO SHOW THE REMAINING 11 SETTINGS
WITH THEIR CHOICES AS LISTED ABOVE.
THE 'AUXI' BUTTON WILL
CYCLE THRU EACH CHOICES RANGE. THE 'START' BUTTON WILL
ACCEPT THE CURRENT SELECTION. THE 'AUX2' BUTTON WILL CHANGE
THE DISPLAY TO THE NEXT VARIABLE. AFTER ALL 11 ARE SHOWN,
THE GAME WILL AUTOMATICALLY GO INTO THE ATTRACT MODE AND WILL
BE READY TO PLAY.
F. GENERAL TROUBLESHOOTING OF SKEE-BALL LIGHTNING
PROBLEM RECOMMENDATION
------------------------+------------------------------------
NO DISPLAY : l.MAKE SURE POWER IS APPLIED TO THE
I
I
ALLEY
; 2.CHECK THE CABLE FROM THE
4
#
CONTROLLER TO THE DISPLAY
; 3.FAN SHOULD BE ON, IF NOT REPLACE
8
I
FUSE ON SIDE OF CONTROLLER.
I 4.REPLACE DISPLAY WITH A KNOWN GOOD
I
I
DISPLAY
: 5.CHECK Fl ON CONTROLLER BD.
: 6.REPLACE CONTROLLER
------------------------+------------------------.-------------
DISPLAY NOT SHOWING : l.INSPECT CABLE
PROPER READOUT : 2.REPLACE DISPLAY
------------------------+-----------------------------------
BALL COUNT NOT ACCURATE : l.ADJUST BALL COUNT SWITCH WIRE
I
I
TOWARDS THE BALL IF IT DOES NOT
I
COUNT THE BALL.
: P.ADJUST THE SWITCH WIRE AWAY FROM
I
I
THE BALL IF IT COUNTS ONE BALL AS
I
1
TWO.
3.TOO MANY BALLS IN ALLEY
------------------------+------------------------------------
MISSING BALL COUNT : l.ADJUST THE SWITCH WIRE TO MAKE
I
I
SURE IT CONTACTS THE BALL.
: Z.REPLACE THE SWITCH
3.TOO MANY BALLS IN ALLEY
------------------------+------------------------------------
1
