11. System configuration
Pump settings => Pump settings => Filling/Low Level => Alarm
Step Key Display Description
Alarm Setting for the Alarm system output
5.2
• Press <OK control key>
)You will enter the Alarm Settings menu
• Press <Select control key>
• Use <down/up arrow key> to select Output Type
)The following settings are available:
o normally closed
o normally open
o disabled
• Press <Select control key>
• Use <down/up arrow key> to select Output Type
• Press <Save control key>
)With normally closed and normally open contacts:
• Press <down arrow key>
• Press <Select control key>
• Use <down/up arrow key> to enter the output No.
• Press <Save control key>
• Press <Back control key>
Alarm
Output Type
[normally closed ]
Output No.
[0.00] O
