1.3 Distinguishing features
• Remotecontrolpanel
Toimprovetheeaseofuseandtodiminishtheriskofcontactwiththehot
bearingduringoperation,theTIH030mheaterissuppliedwitharemotecontrol
panelwhichcanbedetachedfromtheheater.
• Inductivecoil
Whenheatedtheworkpieceislocatedatthesamepositiononthecoreasthe
inductivecoil.Thisdesignimprovesefciency,resultinginlesspowerconsumption
andfasterheating,whichreducethecosttoheateachbearing.
• Foldingbearingsupports
TosupportlargebearingpositionedaroundtheinductivecoiltheTIH030m
inductionheateristtedwithfoldingbearingsupports.Seetheillustrationsatthe
beginningofthismanual.
• Yokestorage
Allthreeyokescanbestoredinsidetheheater.Twoyokestoragearelocated
behindthefoldingbearingsupports.Storageofthesmallandmediumyokesis
intheyokestorageattheheatercircuitbreakerside.
Storageofthelargeyokeisintheyokestorageattheheatermainscableside.
Seetheillustrationsatthebeginningofthismanual.
2. Description
Theoperationoftheheateriscontrolledbytheinternalelectronicsineitheroftwo
modes.Theoperatorcaneitherselectthedesiredtemperatureofthebearingin
TEMPMODEorsetthelengthoftimethatthebearingwillbeheatedinTIMEMODE.
Thepowerlevelcanbeadjustedto100%or50%forslowerheatingofsensitive
workpieces(forexample,bearingswithC1orC2clearance).
2.1 Components
TheTIH030minductionheatercontainsaU-shapedironcorewithaninductivecoil
surroundingoneoftheverticalsupports.Adetachableremotecontrolpanelisincluded.
Theremotecontrolelectronicsandtheinternalelectronicscontroltheoperationofthe
heater.Aremovableyokeonthetopoftheverticalsupportsallowstheworkpiecetobe
placedontotheheater.Toaccommodatesmallerworkpieces,twosmalleryokesarealso
provided.Atemperatureprobeisalsoincludedwiththeheater.Heat-resistantglovesare
alsoincluded.
