2.2 Technical data
TIH 030m
Voltage(±10%) 230V/50/60Hzor110-100V/50/60Hz
Recommendedlineprotection 10Afuseratingfor230V
20Afuseratingfor110V
Powerconsumption(maximum) 2,0kVA
Temperaturecontrol 0-250°C(32-482°F);instepsof1°
Probetype Thermocouple,Ktype
Probemaximumtemperature 250°C(482°F)
Timemode 0-60minutes;instepsof0,1minute
Powerrange 100%-50%
Demagnetization automatic;residualmagnetism<2A/cm
Overalldimensions(wxdxh) 460x200x260mm(18.1x7.9x10.2in)
Areabetweensupports(wxh) 100x135mm(3.9x5.3in)
Coildiameter 95mm(3.7in)
Forminimumbearingborediameterof
100mm(3.9in)
Weight(withyokes) 20.9kg(46.0lbs)
Workpiecemaximumweight bearing:40kg(88lbs);
solidcomponent:20kg(44lbs)
Maximumheatingtemperature approx.400°C(752°F)
m
20
* 28kg(bearing23136)
Standardyokedimensions: Forminimumbearingborediameterof:
45x45x215mm(1.7x1.7x8.4in) 65mm(2.6in)
28x28x215mm(1.1x1.1x8.4in) 40mm(1.6in)
14x14x215mm(0.6x0.6x8.4in) 20mm(0.8in)
*m
20
 representstheweight(kg)oftheheaviestSRB231bearingthatcanbeheated
from20to110°C(68to230°F)in20minutes.
English
www.promshop.biz
ЗАО "Берг АБ" (495) 727-22-72 promshop- biz@ya.ru

SKF TIH 030M Specifications

General

Frequency	50-60 Hz
Maximum Bearing Weight	40 kg
Maximum Bearing Diameter	300 mm
Temperature Control	Yes
Magnetic Temperature Probe	Yes
Demagnetization	Automatic
Housing Material	Steel
Voltage	230 V
Operating Temperature Range	0-40 °C
