9SKF TMBH 1
English
5.1 Fault finding
In case of certain malfunctions, the operator will be guided by an error code appearing on
the display:
Display Fault Action
E 00 E Electronic failure Return to SKF for repair
E 01 E Electronic failure Return to SKF for repair
E 02 E Electronic failure Return to SKF for repair
E 03 E Overheating in housing Wait for unit to cool down
E 04 E
Selected time / temperature out of range
Adjust time / temperature setting
E 05 E Temperature increase below
1 degree per 15 s.
Check that the probe is properly
attached to the workpiece or
change to TIME MODE
E 06 E
Temperature probe not connected or defect
Check the prob
E 07 E Temperature above 200 °C (392 °F) Stop heating
E 08 E Clamp is open Close the clamp
E 09 E Clamp not plugged in or broken Plug in or change the clamp
6. Spare parts list
Designation Description
TMBH 1-1 Control box (complete)
TMBH 1-1A Logic print
TMBH 1-1B Power print
TMBH 1-1D Housing cover (including keyboard foil)
TMBH 1-1E Keyboard foil
TMBH 1-1F Mains inlet connector (female Euro-connector)
TMBH 1-1G Main switch
TMBH 1-2 Heating clamp (including cable and plug)
TMBH 1-2A Heating clamp plug set (male and female part)
TMBH 1-3 Temperature probe (including cable and plug)
TMBH 1-3A Temperature probe plug set (male and female part)
TMBH 1-5 Heating pad
MP524 Instruction manual
WORLDWIDE PATENTS
