5SKF TMBH 1
English
2. Technical data
Designation TMBH 1
Power
Voltage
100–240 V, 50–60 Hz
Power (maximum)
350 Watt
Cosine φ
> 0,95
Component size range
Inner diameter
20 ... 100 mm (0.8 ... 4 in.)
Width
< 50 mm (2 in.)
Weight
up to approximately 5 kg (11 lb)
Control functions
Time control
0–60 minutes
Temperature control
0–200 °C (32–392 °F)
Accuracy temperature control
± 3 °C (± 6 °F)
Maximum temperature
200 °C (392 °F)
Dimensions
Control box
150 ™ 330 ™ 105 mm (6 ™ 13 ™ 4 in.)
Heating clamp
114 ™ 114 mm (4.5 ™ 4.5 in.)
Operating space heating clamp
52 ™ 52 mm (2 ™ 2 in.)
Complete unit in carrying case
370 ™ 240 ™ 130 mm (15 ™ 9 ™ 5 in.)
Length clamp cable
75 cm (30 in.)
Length power cable
2 m (80 in.)
Length temperature probe cable
100 cm (40 in.)
Weight complete unit
4,5 kg (10 lb)
