38
Front Grab Handles/Front Bumper
To be used whenever front of snowmobile requires lifting.
1. Front grab handles
Storage Compartment/Tool Kit
Depending on model, a storage compartment is provided in engine
compartment, under seat or inside seat. A tool kit containing tools
for basic maintenance can be found there on some models.
For tool kit location on all models except Formula III, Mach 1/Z and
Skandic WT/SWT, see Belt Guard Removal and Installation.
Skandic WT/SWT Only
A storage compartment is provided under seat. A tool kit containing
tools for basic maintenance can be found there. To open storage
comportment, lift seat latch then tip seat over.
-
CAUTION
Do not use skis to pull or lift snowmobile.
1
A03H0KA
