134
Start the engine and accelerate slightly so that track barely turns. This
must be done in a short period of time (1 to 2 minutes). Check that
the track is well centered; equal distance on both sides between
edges of track guides and slider shoes.
TYPICAL
1. Guides
2. Slider shoes
3. Equal distance
To correct, stop the engine: Loosen rear wheel screws tighten the
adjustment screw on side where the slider shoe is the farthest from
the track insert guides.
TYPICAL
1. Guides
2. Slider shoes
3. Tighten on this side
A01F05A
1
2
3
A01F0BA
1
2
3
1
Mmo2003-003a.book Page 134 Tuesday, March 19, 2002 2:22 PM
