Section 06 REAR SUSPENSION
Sub-Section 02 (SC-10 SUSPENSION (HP VERSION))
06-02-7
If suspecting an internal gas leak between oil
chamber and gas chamber, check shock as fol-
lows:
Install shock in a vise clamping on its bottom eye-
let with its rod upward.
Let it stand for 5 minutes.
Completely push down the shock rod then re-
lease.
Rod must comes out at a steady speed. If speed
suddenly increases particularly at end of exten-
sion, replace shock.
If suspecting a frozen gas shock proceed as fol-
lows:
Place shock in a freezer (temperature below 0°C
(32°F)) for 4 hours.
Push down on rod and note its resistance, com-
pare to a new shock. If shock is frozen it will be
much more difficult to compress than for the new
one.
25, Protector
At assembly, mount protector with its notch to-
ward front.
1. Notch
INSTALLATION
Install assembled suspension into track with front
portion first.
Insert rear portion of suspension into track.
Bolt front arm, rear arm then center top idler
wheel axle.
Adjust track tension.
RIDE ADJUSTMENT
Refer to
Operator’s Guide
.
LUBRICATION
Lubricate front and rear arms at grease fittings us-
ing low temperature grease (P/N 413 7061 00).
SC-10 HP: 7 GREASE FITTINGS
A03F1RA
1
A03F1SA
