-7-
81&7,21$/(6&5,37,21$1'3(&,),&$7,216
,6&211(&7 7+( 3/8* )520 7+( 32:(5 6285&( %()25( 0$.,1* $1<
$66(0%/<$'-8670(17625&+$1*,1*$&&(6625,(6. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
,*6$:
FIG. 1
CORD
VENTILATION
OPENINGS
BLADE
HOLDER
TOP OF FRONT
HOUSING
FOOT
TRIGGER
SWITCH
GEAR
HOUSING
ROLLER
GUIDE
“LOCK-ON”
BUTTON
For tool specifications refer to the nameplate on your tool.
DUST PORT
FINGER
GUARD
ALLEN WRENCH
3 MM
VENTILATION
OPENINGS
Model number 4232
Blade Action Standard
Stroke Length 19 mm
Maximum Capacities
Wood 55 mm
Aluminum 6 mm
Steel 3 mm
1 mm = .039 inches
ALLEN
WRENCH
2.5 MM
