GET TO KNOW YOUR CORDLESS SHEAR/SHRUBBER
20V Cordless Shear/Shrubber (Fig. 1)
Fig. 1
Shrub shear blade
Ventilation
slots
Safety switch
Handle
Shrub Shear Blade Cover
Blade release button
Easy storage hook
Trigger switch
Grass shear blade
Grass Shear
Blade Cover
Easy storage rail
SPECIFICATIONS
Rated Voltage 20 V d.c.
Length of Shrub Shear Blade 7-7/8 in. (200mm)
Width of Grass Shear Blade 4-23/32 in. (120mm)
Max Cutting Capacity 5/16 in. (8mm)
No-Load Speed 1050/min (RPM)
Recommended operating temperature 14 – 104°F (-10 – 40°C)
Recommended storage temperature 32 – 104°F (0 – 40°C)
Ingress Protection Rating IPX1*
* NOTE:
IPX1 rating is based on the machine and battery being used together as a system.
The battery and charger manuals are provided separately, including the special safety rules.
Please refer to the single manual.
