– Fill up coolant to “Max” marking.
Note
Hose connections and air guide pipes and hoses must be free of
oil and grease before being installed.
– Install the noise insulation ⇒ General body repairs, exterior;
Rep. gr. 66 ; Noise insulation; Summary of components -
noise insulation .
– For vehicles with auxiliary heating, switch it on for approxi‐
mately 30 seconds.
– Set temperature to “HI”.
– Switch off AC compressor – press AC to do so.
• The LED in the button must not illuminate.
– Connect vehicle diagnosis tester
.
– Switch on the ignition and select the following options on the
vehicle diagnosis tester :
♦ 0001 - Coolant circuit filling
– Follow the instructions on the vehicle diagnosis tester .
– Check coolant level after repair.
• If the engine is at operating temperature, the coolant level
must not be above the »welding seam« -arrow-.
• If the engine is cold, the coolant level must be approx. 5 mm
-arrow- above the Max marking.
Note
The higher coolant level is necessary, as the coolant level may
still fall after bleeding.
1.4 Flushing the cooling system
The cooling system must be flushed after the following compo‐
nents are replaced:
♦ Cylinder head
♦ Heat exchanger for heating
Karoq 2018 ➤ , Kodiaq 2017 ➤
1.6/85; 2.0/110; 130; 140 kW TDI CR engine - Edition 06.2017
1. Cooling system, coolant 167
