To Next PageTo Next PageWhy is my Skov Fan making abnormal noise?
If the Skov Fan is making abnormal noises, it could be due to several reasons. First, check the mounting to ensure it aligns with the provided documentation, and retighten if necessary. The noise might also be from the bearings, in which case the motor should be replaced. Additionally, examine the fan blades for defects, proper assembly, or dirt; replace or clean them as needed.
What to do if the Skov DA 820 LPC -3 Fan inlet flap is not operating?
If the Skov Fan inlet flap isn't operating, first, verify the 24 V DC supply voltage and check the assembly against the connection and circuit diagram. Also, if the gear motor isn't running, check if the connector is properly mounted, and replace the gear motor if necessary.
How to fix a Skov DA 820 LPC -3 inlet flap that won't close or open?
If the Skov Fan inlet flap will not close or open, it may be obstructed by the ventilation duct. Remedy the damage. Alternatively, the linkage between the flap and gear may be faulty, in which case you should replace the defective parts. If there is no ON/OFF signal from controller / manual operation, see section cable plans and circuit diagrams.
What does 'O-I' mean on my Skov Fan?
The 'O-I' error on your Skov Fan indicates an overcurrent on the output of the motor controller, meaning the motor's power consumption is too high. The motor controller cannot be reset immediately due to a built-in time delay; see section Resetting errors.
What does 'h O-I' error mean on Skov DA 820 LPC -3?
The 'h O-I' error on your Skov Fan indicates an overcurrent on the output of the motor controller, meaning the motor's power consumption is too high. The motor controller cannot be reset immediately due to a built-in time delay; see section Resetting errors.
What does 'O-hEAt' mean on a Skov DA 820 LPC -3?
The 'O-hEAt' error indicates that the internal temperature of the motor controller is too high. Ensure that the ambient temperature and distance requirements are in line with the specifications.
What does 'O-t' mean on my Skov DA 820 LPC -3 Fan?
The 'O-t' error on your Skov Fan indicates over temperature on the heat sink. Verify that the ambient temperature and distance requirements meet the specified guidelines.
What does 'U-volt' mean on a Skov DA 820 LPC -3?
The 'U-volt' error on your Skov Fan means there's an under voltage on the DC bus. This often happens when the supply voltage is too low or if the power to the motor controller is interrupted. Check the supply voltage and all components in the supply.
What does 'O-volt' mean on my Skov Fan?
The 'O-volt' error on your Skov Fan indicates over voltage on the DC bus. Verify that the supply voltage is within the allowable range.
What does 'I_t-trP' mean on my Skov DA 820 LPC -3 Fan?
The 'I_t-trP' error on your Skov Fan indicates a motor thermal overload (I2t). This appears after delivering > 100 % of the value in settings for a period of time to prevent damage to the motor.
Importance of separate alarm systems for livestock climate control.
Copyright, reproduction, accuracy, and liability disclaimers for SKOV A/S.
Details of 230V and 400V DA 820 LPC-3 fan models.
List of tools required for mounting the fan unit.
Instructions on fan orientation and mounting within exhaust units.
Minimum safety distance to fan blades and protective mesh requirements.
Guidelines for positioning the motor controller for proper function.
Required clearances around the motor controller for cooling and access.
Recommended ambient temperature and mounting locations for the controller.
Safety precautions and general guidelines for electrical connections.
Recommendations for involving local experts when retrofitting fans.
Importance of proper mains supply sizing due to harmonic distortion.
Recommendations for Surge Protection Devices (SPD) installation.
Instructions for routing fan cables within the exhaust unit.
Methods for preventing water ingress into the motor controller via cabling.
Detailed overview of terminals and connections within the LPC motor controller.
Connecting one-phase power supply to the motor controller terminals.
Connecting three-phase power supply to the motor controller terminals.
Connecting the motor controller to the fan motor terminals.
Description of signal terminal functions and connections.
Explanation of LED indicators on the motor controller display.
Overview of the motor controller's operational buttons and functions.
Step-by-step guide to changing analog input signal from 10-0 V to 0-10 V.
Instructions for setting jumpers and making connections on the PCB.
Standard color coding for electrical wires used in diagrams.
Diagram and explanation for the required power supply isolator.
Explanation of letter codes used in circuit diagrams per IEC/EN 61346-2.
Circuit diagram for control voltage with DA 74CO (OFF/AUTO/ON).
Circuit diagram for control voltage with DA 74CV (stepless).
Cable plan for DA 820 LPC-3 1x230 V connection.
Terminal connections for the LPC 230 V fan.
Cable plan for DA 820 LPC-3 230V with DA 74CO.
Terminal connections for the LPC 230 V fan with DA 74CO.
Cable plan for DA 820 LPC-3 230V with thermal cutout and DA 74CO.
Terminal connections for LPC 230V fan with thermal cutout.
Cable plan for DA 820 LPC-3 230V with DA 74CV stepless.
Terminal connections for the LPC 230 V fan.
Cable plan for DA 820 LPC-3 230V with thermal cutout and DA 74CV.
Terminal connections for LPC 230V fan with thermal cutout.
Cable plan for DA 820 LPC-3 400V with DA 74CO.
Terminal connections for the LPC 400 V fan.
Cable plan for DA 820 LPC-3 400V with DA 74CV stepless.
Terminal connections for the LPC 400 V fan.
Cable plan for DA 820 LPC-3/DA 74CV stepless with reverse function.
Circuit diagram for DA 820 LPC-3/DA 74CV stepless with reverse.
Cable plan for DA 820 LPC/DA 74CV stepless with alarm relay.
Circuit diagram for DA 820 LPC/DA 74CV stepless with alarm relay.
Instructions for cleaning the fan and motor controller.
Information on product recycling and disposal according to local instructions.
Guides for diagnosing and resolving issues with the fan and inlet flap.
Detailed list of error codes and their solutions for the LPC motor controller.
Methods for resetting motor controller errors and understanding time delays.
Technical specifications for the DA 820 LPC-3 1x230 V fan models.
Ecodesign and efficiency classification data for 1x230V models.
Technical specifications for the DA 820 LPC-3 3x400 V fan models.
Ecodesign and efficiency classification data for 3x400V models.
Diagrams showing the physical dimensions of the LPC motor controller and fan.
General
