9V-36V 9V-36V
9V-36V 9V-36V
9V-36V 9V-36V
9V-36V 9V-36V
T6
max. 0,15Nm
BOSCH Gen. 2,3 und 4
Active Line/Performance Line/CX
Front light connection
Yamaha PB-X
Front ligaht connection 12 V
BOSCH Gen. 4
Light connection or 12 V aux.
BAFANG M620
7015-BS-2 12V / 12W
Fazua
JST VSLE 03R connector / 12 V
Shimano / screw terminals
Light connection 12 V
Brose S
Front light connection 12 V
Panasonic
Light connection max. 36 V
3. Attach the COM/PAD
Place the COM/PAD on the COMPIT and turn it (about 45°)
either to the right or left above the docking station until
you hear it click into place.
OPTIONAL!
Screw in the anti-theft lock screw as far as it will go.
Mounting the COM/PAD
33
