January 2019 Page 4
HOIST SPECIFICATIONS & CHARACTERISTICS
Compact 1000, 1250 & 1500
Air & Electric Motors
Detachable Sky
Lock Type III
Secondary Brake
“No Power”
Emergency
Controlled Descent,
Meets or Exceeds
OSHA requirements
U. L. Classified
Maximum Rated
Capacity (MRC)
is total load
supported by Hoist.
It includes the
combined weights of
the stirrup, platform,
work cage, bosun
chair, personnel,
work tools or
materials, operating
accessories, power
cord, wire rope, and
hoists.
Compact 1000 & 1250 (Gast)
Power: 70 CFM
PSI: 100
Hoist Weight: 74 lbs.
Ascent Speed: 35 fpm
Descent Speed: 35 fpm
Sky Lock III: Included with Hoist
Wire Rope: 5/16”
Filter & Lubricator: Included with Hoist
Part #: KCA-1000-Air
KCA-1250-Ai
PNEUMATIC (AIR)
SPECIFICATIONS
Single Volt 1000 & 1250 Single Volt 1500
Power: 1.3 HP / KW 0.95 1.3 HP / KW 0.95
Line Current: 7.5 Amps 9.24 Amps
Power Cable: 14/3 14/3
Voltage: 230 VAC / 60 Hz 1 PH 230 VAC / 60 Hz 1 PH
Hoist Weight: 104 lbs. 123 lbs.
Sky Lock III: Included with Hoist Included with Hoist
Wire Rope: 5/16” 5/16”
Ascent Speed: 32 fpm 32 fpm
Descent Speed: 35 fpm 35 fpm
Pendant Control: Hoist Mounted Ctrl w/plug Hoist Mounted Ctrl w/plug
Part #: KCE-1000-220 KCE-1500-220
KCE-1250-220
RPM: 1725 1725
ELECTRICAL
SPECIFICATIONS
220v MOTORS
Single Volt 1000 & 1250 Single Volt 1500
Power: 1.2 HP / KW 0.88 1.2 HP / KW 0.88
Line Current: 9.0 Amps 9.0 Amps
Power Cable: 14/3 14/3
Voltage: 208 VAC / 60 Hz 1 PH 208 VAC / 60 Hz 1 PH
Hoist Weight: 104 lbs. 104 lbs.
Sky Lock III: Included with Hoist Included with Hoist
Wire Rope: 5/16” 5/16”
Ascent Speed: 32 fpm 32 fpm
Descent Speed: 35 fpm 35 fpm
Pendant Control: Hoist Mounted Ctrl w/plug Hoist Mounted Ctrl w/plug
Part #: KCE-1000-208 KCE-1500-208
KCE-1250-208
RPM: 1685 1685
ELECTRICAL
SPECIFICATIONS
208v MOTORS
