2.
4.
4.
a)
b)
c)
d)
e)
3.
3.
Enter the function the display will show indicating that it is enabled.
Enter the function the display will show that comes by default.
Press to record the selected program and return to menu. The display will show
Press to record the selected program and return to menu. The display will show
With photocells installed and working correctly,
when operating the gate and they are obstructed, the display will show , and then:
In programs 1, 2, 4 and 5 to beam interruption during closing causes reverse movement of the gate.
The display will show , or as the photocell that has been activated.
In program 3 the interruption of the beam during the closure will stop the gate. The display will show
, or as the photocell. You will need a new ‘start’ to restart the closing of the gate.
In program 6 the interruption of the beam during the closure will stop the gate. The display will show
, or as the photocell that has been activated.
As soon as these are unobstructed the process returns to normal.
Choose between to disable or to enable the change of phases.
Choosing between to NC (Normally close), or for NO (normally open).
Use the buttons or to select enabled or disabled mode.
P
P
+
-
1.
1.
NOTE: Should be always enabled the phases protection, in order to protect the engine.
Photocells installation
2.
Use the buttons or to select the operation mode of the photocells.
+
-
NOTE:
NOTE:
NOTE:
Only the safety contact IR1 can be programmed to NC or NO. IR2 and IR3’s contacts will always be NC.
If no photocells are installed, shunt the contacts 2-3, 5-6, 8-9 in X3.
When a safety contact is activated, the display will show , or as the contact of the
device that has been activated.
Phases protection
Problems with the emer-
gency button / STOP, with
the motor connection
cable and data cable.
Failure to chain hoist
system or tuning the
limit switches setting.
Problems in phases
protection.
Fault code
