7 . Ope n in g a nd Clo si n g Trave l Limit S e tt ing
⑴ Release the clutches of both gearmotors with a release key, open
both gate leaves completely, then engage the clutches.
⑵ Put DIP switch SW2 N o.8 to ON position.
ST
mai n board
ST
s w itch
8 . Tr a nsmitte r p r o g r am m ing
1. Memorizing a new trans mit ter
Put DIP swit ch 4 on SW1 t o ON:
a.Program ming transmi tter b utton for b oth leaves:
CODE
Press and hold for 2S, the code LED DL6 is on, pres s button 1
But ton1
But ton2
of the t ransm itt er twice, t he code LED DL6
is off, butt on 1 can o perate bot h leaves.
b.Programm ing trans mit ter but ton fo r si ngle l eaf :
CODE
CODE
Press and hold for 2S, the code LED DL6 is on, pres s again,
But ton 1
But ton 2
the code LED DL6 is flashing, press butt on 2 of the
transmi tter t wi ce, the code LED DL6 is off, button 2
can operate one of the leaves.
Note: 1. When the code LED DL6 is flashing, if the user does not need to
CODE
programme transmitter button for single leaf, press
t o exi t the programmin g.
button
2. The cont rol u nit can memorize Max. 25 pcs trans mit ters.
3. If b utton 1 is for both leaves, but ton 2 is for si ngle leaf, it i s invalid
to code but ton 1 for sing le l eaf.
4. If b utton 1 is for both leaves, but ton 2 is for si ngle leaf, now t he
user program mes b utton 2 for bot h leaves, then butt on 1 wil l be
invail d at the same t ime.
2 . Del et ing al l transmit ters:
CODE
P re s s an d ho ld fo r 10 S to d elet e a ll tr an s mi tte r
s.
(Not e: If t he pro ced ur e is pe rfor me d c orr ec tly, pre ss t he bu tton s o f a
ny tr an s mi tte r s can no t op era te the un i t).
9 . Fun ct ion I n tr o d u ct ion
(1)
( The delay time is set at 2 seconds in factory)
1-3
1
3
2
1 se co nd
3S
I f w it ho ut an y o pe ni ng / cl os in g d el ay s et ti ng , th e d ef au lt de l ay ti me is 1S.
No te :S wi tc h 3 o n S W2 i s fo r re se rv ati on.
