Skybox Security Skybox 5500 - Environmental specifications

Chapter 2 Skybox 5500 specifications
Skybox 5500 Appliance 7
Feature Description
System cooling
• Two dual rotor managed 40mm x 56mm system fans
• One 40mm x 40mm system fan
•
Two power supply fans
Front panel features
• 1 power button with integrated LED
• 1 system ID button with integrated LED
• 1 system status LED
• 4 NIC LEDs
• 1 HDD activity LED
• 1 system cold reset button
• 2 USB 2.0 connectors
•
Bezel with lock support
External I/O
connectors
(back panel)
• DB-15 video connector
• DB-9 serial port A connector
• 2 USB 2.0 Ports
• 2 USB 3.0 Ports
• Six RJ-45 network interface (LAN) connectors supporting
10/100/1000 Mb
Compliant standards Ctick, NRTL, CE, FCC, EMC, BSMI, KC, and more
Note: For detailed information, see Regulatory and safety
information (on page 22).
Environmental specifications
Environmental specifications for Skybox 5500 are listed in the following table.
Parameter Limits
Operating
temperature
+10° C to +35° C with the maximum rate of change not to exceed
10° C per hour
Non-operating
temperature
-40° C to +70° C
Non-operating
humidity
50% to 90%, non-condensing with a maximum wet bulb of 28° C
Acoustic noise Sound pressure: 55 dBA (rack mount) in an idle state at typical
office ambient temperature. (23 C +/- 2 C)
Sound power: 7.0 dBA in an idle state at typical office ambient
temperature. (23 +/- 2 degrees C)
Shock, operating Half sine, 2 g peak, 11 msec
Shock, unpackaged Trapezoidal, 25 g, velocity change is based on packaged weight
Shock, packaged
Non-palletized free fall height 18 inches (
≧
40 lbs to > 80 lbs)
Vibration Unpackaged: 5 Hz to 500 Hz, 2.20 g RMS random
Packaged: 5 Hz to 500 Hz, 1.09 g RMS random
ESD Air discharge: 12.0 kV
