Skybrake TOUCH - Fault Finding Chart

7
Also there are sound notications used to show the security system status (see table):
Operation
Sound signal
System ready (after ignition switched ON) 1 short beep
Pressing any soft key 1 short beep
Conrming correct PIN code 2 short
beeps
Conrming incorrect PIN code 1 long beep
Conrming correct Overriding PIN code 6 short
beeps
Conrming incorrect Overriding PIN code 1 long beep
Low battery warning for Personal Transceiver 4 short beeps
FAULT FINDING CHART
Personal Transceiver not working
Is the Personal Transceiver with in a 5 metre range.
Remove battery and wait ve minutes, re-insert battery and check red LED on printed circuit board ashes
once (refer to the Personal Transceiver Replacement Battery section)
Disassemble Personal Transceiver and replace battery
Keypad not accepting Master code
Is the correct code being entered
Is the code being conrmed by pressing the # button
Reset keypad memory back to factory settings using the PIN code card. (refer to PIN Code Card section)
Can not change Master code
Is the current Master code been entered correctly
Has the
*
and # buttons been pressed together within 5 seconds
Is the code being conrmed by pressing the # button
Has the new Master code been entered correctly twice and conrmed
Is the correct memory location of “0” being used and conrmed by pressing the # button
Not able to add a User code
Has the
*
and # buttons been pressed together within 5 seconds
Is the Master code being entered rst to conrm authority
Has the new User code been entered correctly twice and conrmed
Is the 1 to 5 memory location being entered and conrmed by pressing the # button
Not able to delete a User code
Is the Master code being entered rst to conrm authority
Is the 1 to 5 memory location being entered and conrmed by pressing the # button
Reset keypad memory back to factory reset. This will delete all data and set the Master code to “0000”. The
Master code will need to be changed, and all User codes re-entered
Keypad Red LED not working
Is the ignition switched on
Is the Personal Transceiver with in a 5 metre range
Refer to installation manual to diagnose wiring fault
