SECTION 6, Page 25SJIII Series - The Conventionals 129919
Index
No.
Skyjack
Part No.
DescriptionQty.
10208AB
Figure 6.1-14. Powered Extension Platform Valve Solenoid Cable
A 126109 - ASSEMBLY, Hydraulic extension platform solenoid cable
1 103257 142” • CABLE, 18/3 Cabtire
2 107712 1 • CONNECTOR, 5 Pin male
3 102734 10” • WIRE, White 16 AWG
4 300742 4 • TERMINAL, Female disconnect 14-16GA
1
2
4
3
AG
